Designed for last-mile/pool transport operations: adequate space + load-capability on urban roads.
Product Modules
Performance
Fuel Type – Diesel
Fuel Tank Capacity – 10.5 Ltr
Engine – Four Stroke, Air Cooled
Displacement – 435 cc
Max Power – 5.70 kW
Max Torque – 19.2 Nm
Gross Weight – 784 kg
Kerb Weight – 464 kg
Electrical System – 12 V DC / 55 A
Tyre Details
Number of Tyres – 3
Front Tyre Size – 4.00 – 8-4 PR
Rear Tyre Size – 4.00 – 8-4 PR
Brakes & Suspension
Brakes – Dual Type, Dual Circuit, Hydraulic, Front & Rear combined with TMC
Front Suspension – Helical Compression Spring and Damper
Rear Suspension – Helical Compression Spring and Damper
ABS – No
Parking Brake – Yes
Clutch Transmision
Gearbox – 4 Forward + 1 Reverse
Transmission – Constant Mesh | Multi Plate Wet Type
Steering – Handlebar Type
Auto Body Cabin
Body Option – Fully Built
Seating Capacity – Driver + 3 Passenger
Chassis Type – Monocoque Chassis
Cabin Variant – Day Cabin
Dimensions
Overall Length – 2765 mm
Overall Width – 1420 mm
Overall Height – 1800 mm
Wheel Base – 1950 mm
Ground Clearance – 185 mm
