The Atul RIK is one of Atul Auto’s flagship passenger and cargo vehicles, known for fuel efficiency, strong performance, and low maintenance.
Product Modules
Performance
Fuel Type – CNG
Fuel Tank Capacity – 30 L CNG / Petrol 2.8 L
Engine – Four Stroke Single Cylinder
Displacement – 200 cc
Max Power – 7.35 kW (9.86 hp) @ 5750 + 250 rpm
Max Torque – 14.7 Nm at 3000 +250 rpm
Cooling – Air Cooled Engine
Gross Weight – 748 kg
Kerb Weight – 428 kg
Electrical System – 12V DC/35 Ah.
Tyre Details
Number of Tyres – 3
Front Tyre Size – 4.00 – 8-4 PR
Rear Tyre Size – 4.00 – 8-4 PR
Brakes & Suspension
Brakes – Dual Type, Dual Circuit, Hydraulic, Front & Rear combined with TMC
Front Suspension – Helical Compression Spring and Damper
Rear Suspension – Helical Compression Spring and Damper
ABS – No
Parking Brake – Yes
Clutch Transmision
Gearbox – 4 Forward + 1 Reverse
Transmission – Constant Mesh | Multi Plate Wet Type
Steering – Handlebar Type
Auto Body Cabin
Body Option – Fully Built
Seating Capacity – Driver + 3 Passenger
Chassis Type – Monocoque Chassis
Cabin Variant – Day Cabin
Dimensions
Overall Length – 2765 mm
Overall Width – 1420 mm
Overall Height – 1800 mm
Wheel Base – 1950 mm
Ground Clearance – 185 mm
